Tektronix MDO3000 Series Program Manual

Commands Listed in Alphabetical Order
Related Commands
CURVe
Arguments
REF<x> is the reference location where the waveform will be stored.
Examples
DATA:DESTINATION? might return :DATA:DESTINATION REF3 indicating that
reference 3 is the currently selected reference memory location for incoming
waveform data.
DATA:DESTINATION REF1 indicates that incoming waveform
data be stored in reference 1.
DATa:ENCdg
This command specifies the encoding format for outgoing waveform data. This
command is equivalent to setting WFMOutpre:ENCdg, WFMOutpre:BN_Fmt,
and WFMOutpre:BYT_Or. Setting the
DATa:ENGdg value causes the
corresponding
WFMOutpre values to be updated.
NOTE. This command and query does not apply to incoming waveform data.
(See page 2-95, Waveform Transfer Command Group.)
(See page D-1, Wa veform Transfer (WFMOutpre and CURVe Query) Examples.)
Group
Waveform Transfer
Syntax
DATa:ENCdg
{ASCIi|FAStest|RIBinary|RPBinary|SRIbi nary|SRPbinary|FPbinary|
SFPbinary}
DATa:ENCdg?
Related Commands
WFMOutpre:ENCdg,
WFMOutpre:BN_Fmt,
WFMOutpre:BYT_Or
Arguments
ASCIi specifies to use ASCII encoding for the waveform data queried using the
CURVe? query. Data values are returned as signed decimal integers for analog
channel and RF time domain data, 4-byte floating point values for RF frequency
domain data, or hexadecimal values for Digital Collection data with 4 or 8 bytes
per point. The maximum number of ASCII data points that can be queried using
the
CURVe? query is 1 million points. If more than 1 million points are desired,
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-275
