Commands Listed in Alphabetical Order
Bit 7 0
Bit 6
If set, invers
e video is toggled from current state and the following text
is displayed in the new inverse state until the state is toggled again.
Remaining bits are ignored
Bit 5
If set, the color index in the four LSB ’s (bits 0 through 3) is applied to
the foregrou
nd or background color depending on the fg/bg bit (bit 4).
Bit 4
If s et, colo
r change is applied to the background, otherwise applies to
the foreground.
Bit0–3
Specifies the c olor index (0 through 15) to change color as specified
below:
Index 0
Black (transparent)
Index 1
Yellow (Ch 1)
Index 2
Cyan (Ch 2 )
Index 3
Magenta (Ch 3)
Index 4
Green (Ch 4)
Index 5
Red (math)
Index 6
White (reference)
Index 7
Orange
Index 8 Black
Inde
x9
Blac
k
Index 10 Blue
Index 11
Dark Green
Index 12 Tan
In
dex 13
Bl
ack
Index 14
Wh
ite (text color)
Index 15 Dark gray
Bit 4
If set, the foreground color is set to the default foreground color.
Bit 3
If set, the background color is set to the default background color.
Bit 2
Undefined
Bit 1
Undefined
Bit 0
Undefined
The ESC (escape) character followed by the @ character turns inverse video on or
off and can be embedded in the message string. Example: “abcESC@defESC@
ghi” specifies the string “abcdefghi” where the “def” portion is displayed in
inverse video.
Example: “abcESC#defESC)ESC@ghi” specifies the string “abcdefghi” where
the “def” portion appears in the channel 3 color (magenta) and the “ghi” portion
appears in the normal text color except it’s in inverse video.
An alternate way to enter characters is octal escape sequences. This consists of a
backslash followed by numerals in the standard C language printf fashion.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-455
