Tektronix MDO3000 Series Program Manual

Commands Listed in Alphabetical Order
Arguments
QString is a quo
ted string of 19, 21, or 23 bits. The allowable characters are 0,
1, and X. The bits specified in the quoted string replace the least significant bits,
leaving any unspecified upper bits unchanged.
NOTE. The size of the QString is dependent on the data field format selected using
BUS:B<x>:ARINC429A:DATA:FORMAT. Also, the store d QString is reset to its
default value whenever the data field format is changed.
Examples
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:DATA:HIVALue
"XXXXXXXXXXXXXXX1000" sets the upper limit of the range to
XXXXXXXXXXXXXXX1000.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:DATA:HIVALue?
might return "XXXXXXXXXXXXXXXXXXX".
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:DATA:QUALifier
This command specifies the qualifier to be used when searching on the ARINC429
data field(s). The search condition must be set to DATA or LABELANDDATA.
The default qualifier is “Equal to”. SEARCH<x> is the search number, which
is always 1. B<x> is the bus number.
Conditions
This command requires installation of a DPO4AERO application module for
MDO4000C models, or MDO3AERO for MDO3000 models.
Group
Search
Syntax
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:DATA:QUALifier
{LESSthan|MOREthan|Equal|UNEQual|LESSE Qual|MOREEQual|
INrange|OUTrange}
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:AR INC429A:DATA:
QUALifier?
Related Commands
BUS:B<x>:ARINC429A:DATA:FORMAT
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:CONDition
SEARCH:SEARCH
<x>:TRIGger:A:BUS:B<x>:ARINC429A:DATA:HIVALue
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:DATA:VALue
Arguments
LESSthan sets data qualifier to less than.
MOREthan sets the data qualifier to greater than.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-613
