Tektronix MDO3000 Series Program Manual

Commands Listed in Alphabetical Order
Examples
TRIGger:A:BUS
:B<x>:ARINC429A:DATA:QUALifier LESSthan
sets the
label qualifier to less than.
TRIGger:A:BU
S:B<x>:ARINC429A:DATA:QUALifier?
might return EQUAL
indicating the label qualifier is set to =.
TRIGger:A:BUS:B<x>:ARINC429A:DATA:VALue
This command specifies the low value to be used when triggering on the
ARINC429 bus data field(s). The trigger condition must be set to DATA or
LABELANDDATA (using TRIGger:A:BUS:B<x>:ARINC429A:CONDition).
The defau
lt is all X's (don't care). B<x> is the bus number.
Conditions
This command requires installation of a DPO4AERO application module for
MDO4000C models, or MDO3AERO for MDO3000 models.
Group
Trigger
Syntax
TRIGger:A:BUS:B<x>:ARINC429A:DATA:VALu e <QString>
TRIGger:A:BUS:B<x>:ARINC429A:DATA:VALu e?
Related Commands
BUS:B<x>:ARINC429A:DATA:FORMAT
TRIGger:A:BUS:B<x>:ARINC429A:CONDition
TRIGger:A:BUS:B<x>:ARINC429A:DATA:HIVALue
TRIGger:A:BUS:B<x>:ARINC429A:DATA:QUALifier
Arguments
QString is a quoted string of 19, 21, or 23 bits. The allowable characters are0,
1, and X. The bits specified in the quoted string replace the least significant bits,
leaving any unspecified upper bits unchanged.
NOTE. The size of the QString is dependent on the data field format selected using
BUS:B<x>:ARINC429A:DATA:FORMAT. Also, the store d QString is reset to its
default value whenever the data field format is changed.
Examples
TRIGger:A:BUS:B<x>:ARINC429A:DATA:VALu e
"XXXXXXXXXXXXXXX1000" sets the data field value to
XXXXXXXXXXXXXXX1000.
TRIGger:A:BUS:B<x>:ARINC429A:DATA:VALu e? might return
"XXXXXXXXXXXXXXXXXXX".
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-777
