Tektronix MDO3000 Series Program Manual

Commands Listed in Alphabetical Order
FLEXRay specifi
es the FLexRay bus.
AUDio specifies the audio bus.
ETHERnet specifies the Ethernet bus.
MIL1553B specifies the MIL-STD-1553 bus.
TRIGger:A:BUS:B<x>:ARINC429A:CONDition
This command sets the condition (word start, label, matching data, word end, or
error) to b
e used to trigger on CAN bus data. B<x> is the bus number.
Conditions
This command requires installation of a DPO4AERO application module for
MDO4000C models, or MDO3AERO for MDO3000 models.
Group
Trigger
Syntax
TRIGger:A:BUS:B<x>:ARINC429A:CONDition
{STARt|END|LABel|DATA|LABELANDDATA|ERR or}
TRIGger:A:BUS:B<x>:ARINC429A:CONDition ?
Related Commands
Most of the other TRIGger:A:BUS:B<x>:ARINC429A commands are impacted
by the setting of this command.
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:ARINC429A:CONDition
TRIGger:A:BUS:B<x>:ARINC429A:ERRTYPE
BUS:B<x>:ARINC429A:SOUrce
Arguments
STARt enables triggering on the first bit of a word.
END enables triggering on the 32nd bit of a word.
LABel enables trigger on a matching label.
DATA enables triggering on matching packet data field(s).
LABELANDDATA enables triggering on matching label and matching packet data
field(s).
ERROR enables triggering on a specified packet error.
NOTE. The type of error triggered on is specified by TRIGger:A:BUS:B<x>:
ARINC429A:ERRTYPE
2-774 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
