Commands Listed in Alphabetical Order
Conditions
For I
2
C or SPI bu
s signals, install the DPO4EMBD application module,
except for MDO3000 models, which require MDO3EMBD.
For RS-232, RS
-422, RS-485, or UART bus signals, install the DPO4COMP
module, except for MDO3000 models, which require MDO3COMP.
For I
2
S, Lef
t Justified (LJ), Right Justified (RJ), or TDM bus signals, install
the DPO4AUDIO module, except for MDO3000 models, which require
MDO3AUDIO.
For CAN or LIN bus signals, install the DPO4AUTO or DPO4AUTOMAX
module, except for MDO3000 models, which require MDO3AUTO.
For FlexRay bus signals, install the DPO4AUTOMAX module, except for
MDO3000 models, which require MDO3FLEX.
For Ethernet signals on the MDO4000/B/C and MSO4000B and DPO4000B,
install the DPO4ENET module. Note that ≥350 MHz bandwidth models
are recommended for 100BASE-TX.
For MIL-STD-1553 bus signals, install the DPO4AERO module, except for
MDO3000 models, which require MDO3AERO.
For USB bus signals, install the DPO4USB module, except for
MDO3000 models, which require MDO3USB. Note that 1 GHz bandwidth
models are recommended for high-speed (HS) USB.
A table is available listing the commands enabled by each application module.
(See page H-1, List of Beta Commands and Features.)
Group
Trigger
Syntax
TRIGger:A:BUS
{I2C|SPI|CAN|RS232C|PARallel|USB|LIN|F LEXRay|AUDio|
ETHERnet|MIL1553B}
TRIGger:A:BUS?
Arguments
I2C specifies the Inter-IC bus.
SPI specifies the Serial Peripheral Interface bus (not available on two-channel
models).
CAN specifies the Controller Area Network bus.
RS232C specifies the RS-232C bus.
PARallel specifies the Parallel bus.
USB specifies the USB bus.
LIN specifies the LIN bus.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-773
