Commands Listed in Alphabetical Order
LABELANDDATA (
using TRIGger:A:BUS:B<x>:ARINC429A:CONDition).
The default is all X's (don't care). B<x> is the bus number.
Conditions
This command requires installation of a DPO4AERO application module for
MDO4000C models, or MDO3AERO for MDO3000 models.
Group
Trigger
Syntax
TRIGger:A:BUS:B<x>:ARINC429A:SSM <QString>
TRIGger:A:BUS:B<x>:ARINC429A:SSM?
Related Commands
BUS:B<x>:ARINC429A:DATA:FORMAT
TRIGger:A:BUS:B<x>:ARINC429A:CONDition
Arguments
QString is a quoted string of 2 bits. The allowable characters are 0, 1, and X.
The bits specified in the quoted string replace the least significant bits, leaving
any unspecified upper bits unchanged.
NOTE. The SSM field is only present when the selected data field format is DATA
or SDIDATA (using BUS:B<x>:ARINC429A:DATA:FORMAT). Also, the stored
QString is reset to its default value whenever the data fi eld format is changed.
Examples
TRIGger:A:BUS:B<x>:ARINC429A:SSM "X0" sets the SSM field value to X0.
TRIGger:A:BUS:B<x>:ARINC429A:SSM? might return "XX".
TRIGger:A:BUS:B<x>:AUDio:CONDition
This command sets the condition (start of frame or matching data) to be used
when triggering on an audio bus signal.
B<x> is the bus number (1-4). 1-3 for the
MDO4000C and 1-2 for the MDO3000.
Conditions
This command requires a DPO4AUDIO application module on DPO/MSO4000B
and MDO4000/B/C models and a MDO3AUDIO application module on
MDO3000 models.
Group
Trigger
2-782 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
