Commands Listed in Alphabetical Order
Arguments
ANY
indicates any of the token types.
SOF indicates a SOF (start-of-frame) token type
OUT indicates an OUT token type.
IN indicates an IN token type.
SETUP indicates a SETUP token type.
Examples
TRIGGER:A:BUS:B1:USB:TOKENTYPE SETUP sets the token type to SETUP.
TRIGGER:A:BUS:B1:USB:TOKENTYPE? might return
:TRIGGER:A:BUS:B1:USB:TOKENTYPE SOF if the token type is SOF.
TRIGger:A:BUS:SOUrce
This command specifies the source for a serial or parallel bus trigger, with the
appropriate application module installed.
Conditions
For I
2
C or SPI bus signals, install the DPO4EMBD application module,
except for MDO3000 models, which require MDO3EMBD.
For RS-232, RS-422, RS-485, or UART bus signals, install the DPO4COMP
module, except for MDO3000 models, which require MDO3COMP.
For I
2
S, Left Justified (LJ), Right Justified (RJ), or TDM bus signals, install
the DPO4AUDIO module, except for MDO3000 models, which require
MDO3AUDIO.
For CAN or LIN bus signals, install the DPO4AUTO or DPO4AUTOMAX
module, except for MDO3000 models, which require MDO3AUTO.
For FlexRay bus signals, install the DPO4AUTOMAX module, except for
MDO3000 models, which require MDO3FLEX.
For Ethernet signals on the MDO4000/B/C and MSO4000B and DPO4000B,
install the DPO4ENET module. Note that ≥350 MHz bandwidth models
are recommended for 100BASE-TX.
For MIL-STD-1553 bus signals, install the DPO4AERO module, except for
MDO3000 models, which require MDO3AERO.
For USB bus signals, install the DPO4USB module, except for
MDO3000 models, which require MDO3USB. Note that 1 GHz bandwidth
models are recommended for high-speed (HS) USB.
A table is available listing the commands enabled by each application module.
(See page H-1, List of Beta Commands and Features.)
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-873
