Tektronix MDO3000 Series Program Manual

Commands Listed in Alphabetical Order
Examples
WFMinpre:SPAN
500.0E+6
sets the span to 500 MHz.
WFMinpre:SPAN? might return 500.0E+6, indicating that the span has been set
to 500 MHz.
WFMInpre:WFMTYPe
This comman
d specifies the type of waveform that is being transferred to the
oscilloscope for storage in one of the REF1 - REF4 memory locations. The
waveform type possibilities are the ANALOG, the RF time domain waveforms
(RF_TD), or the RF frequency domain waveforms (RF_FD). The default is
ANALOG. This parameter should be set before using the
CURVe command to
transfer a waveform from a PC to an internal reference location.
The type of waveform that is being transferred in turn determines which window
will display it on the instrument screen: the time domain window or frequency
domain w
indow. Both the analog and RF-TD arguments specify the time domain
window; the RF_FD argument specifies the frequency domain window.
NOTE. This command is not applicable for digital waveforms.
Conditions
The RF_FD type waveform is only supported on MDO4000/B/C series models.
The
R
F_TD
type waveform is supported on both MDO4000/B/C and
MDO3000 models.
Group
Waveform Transfer
Syntax
WFMInpre:WFMTYPe {ANALOG|RF_TD|RF_FD}
WFMInpre:WFMTYPe?
Related Commands
WFMInpre:DOMain
Arguments
ANALOG — this type includes Channels 1–4 and the Math waveform, and specifies
to display it in the time domain window.
RF_TD — this type includes the three RF time domain traces (RF Amplitude vs.
Time, RF Frequency vs. Time, and RF Phase vs. Time) and specifies to display it
in the time domain window.
RF_FD — this type includes the four RF frequency domain traces (RF Normal,
RF Average, RF Max Hold, a
nd RF Min Hold) and specifies to display it in the
frequency domain window.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-953
