Getting Acquainted with the Oscilloscope
Identifying I
tems in the Arbitrary Function Generator Display
1. If visible, the output is on
2. AFG label
3. Waveform type, e.g. “Sine”
4. Additive Noise icon
5. Frequ
ency
6. Amplitude
MDO3000 Installation and Safety Instructions 43
