Power-On and Power-Off Procedure
When compensat
ing TPP0250, TPP0500B, and TPP1000 probes on the
MDO3000 Series oscilloscopes:
Each channel c
an store compensation values for 10 individual probes. If you
try to compensate an 11th probe on a channel, the oscilloscope will delete the
values for the least recently used probe and add the values for the new probe.
The oscilloscope will assign default c ompensation values to a TPP0250,
TPP0500B or TPP1000 probe connected to the Aux In channel.
NOTE. A factory calibration will delete all stored compensation v alues
NOTE. A probe compensation failure is most likely due to intermittent connection
of the probe tip or ground connection during the probe compensation operation.
If a failure occurs, the oscilloscope will re-use the old probe compensation values,
if they existed prior to the failed probe compensation operation.
Application Module Free Trial
A 30-day free trial is available for all application modules not installed in your
oscilloscope. The trial period begins when you power on the oscilloscope for
the first time.
After 30 days, you must purchase the module if you want to continue using the
application. To see the date when your free trial period expires:
push the front panel Utility button,
push the lower-bezel Utility Page button,
us
e multipurpose knob a to select Config,
push the lower-bezel About button,
push the Application Modules side menu.
26 MDO3000 Installation and Safety Instructions
