Display Wavefor
morTraceData
4. Push Backligh
t Intensity.
Utility
Page
Display
Backlight
Intensity
High
Graticule
Full
Screen
Annotation
5. Select the intensity level from the resulting
side-bezel
menu. Choices are: High,
Medium, and Low.
Backlight
Intensity
High
Med
Low
Setting Waveform Intensity
1. Push the front-panel Intensity button.
This will bring up the intensity readout on
the display.
2. Rotate multipurpose knob a to s elect the
desired waveform intensity.
3. Rotate multipurpose knob b to select the
desired intensity for the graticule.
4. Push In tensity again to clear the intensity
readout from the display.
100 MDO4000 Series Oscilloscopes User Manual
