Tektronix MSO70000 Series Technical Reference

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-4: DC voltage measurement accuracy (cont.)
Scale setting
Position setting
(Divs) Offset setting
1
Generator setting Accuracy limits
<4GHzmodels
-5
+0.5 V +507 mV +504.25 mV to +509.76 mV
1mV
+5
-0.5 V -507 mV -509.76 mV to -504.25 mV
-5
+0.5 V +516 mV +512.98 mV to +519.03 mV
2mV
+5
-0.5 V -516 mV -519.03 mV to -512.98 mV
-5
+0.5 V +540 mV +536.26 mV to +543.74 mV
5mV
+5
-0.5 V -540 mV -543.74 mV to -536.26 mV
-5
+0.5 V +580 mV +574.20 mV to +585.80 mV
10 mV
+5
-0.5 V -580 mV -585.80 mV to -574.20 mV
-5
+0.5 V +660 mV +651.65 mV to +668.35 mV
20 mV
+5
-0.5 V -660 mV -668.35 mV to -651.65 mV
-5
+0.5 V +900 mV +884.00 mV to +916.00 mV
50 mV
+5
-0.5 V -900 mV -916.00 mV to -884.00 mV
-5
+0.5 V +1.22 V +1.194 V to +1.246 V
90 mV
+5
-0.5 V -1.22 V -1.246 V to -1.194 V
0 +4.5 V +4.8 V +4.746 V to +4.854 V100 mV
0 -4.5 V -4.8 V -4.854 V to -4.746 V
-2 +4.6 V +4.8 V +4.725 V to +4.875 V200 mV
+2 -4.6 V -4.8 V -4.875 V to -4.725 V
-2 +5.0 V +4.5 V +4.345 V to +4.655 V500 mV
+2 -5.0 V -4.5 V -4.655 V to -4.345 V
0 +2.0 V +5.0 V +4.745 V to +5.255 V1V
0 -2.0 V -5.0 V -5.255 V to -4.745 V
1
Se
t as precisely as the instrument’s offset resolution permits.
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 3–45
