Tektronix MSO70000 Series

Performance Verification (MSO/DPO5000 Series)
Digital Threshold Accuracy, MSO5000 series only
Performance checks:
Digital
channel Threshold V
s–
V
s+
Low limit Test result High limit
0 V -0.1 V 0.1 VD0
4 V 3.88 V 4.12 V
0 V - 0.1 V 0.1 VD1
4 V 3.88 V 4.12 V
0 V -0.1 V 0.1 VD2
4 V 3.88 V 4.12 V
0 V -0.1 V 0.1 VD3
4 V 3.88 V 4.12 V
0 V -0.1 V 0.1 VD4
4 V 3.88 V 4.12 V
0 V -0.1 V 0.1 VD5
4 V 3.88 V 4.12 V
0 V -0.1 V 0.1 VD6
4 V 3.88 V 4.12 V
0 V -0.1 V 0.1 VD7
4 V 3.88 V 4.12 V
0 V -0.1 V 0.1 VD8
4 V 3.88 V 4.12 V
0V -0.1
V
0.1 VD9
4 V 3.88 V 4.12 V
0 V -0.1 V 0.1 VD10
4V 3.8
8V
4.1
2V
0 V -0.1 V 0.1 VD11
4 V 3.88 V 4.12 V
0V -0
.1 V
0.
1V
D1
2
4 V 3.88 V 4.12 V
0 V -0.1 V 0.1 VD13
4
V
3
.88 V
4
.12 V
0 V -0.1 V 0.1 VD14
4 V 3.88 V 4.12 V
0 V -0.1 V 0.1 VD15
4 V 3.88 V 4.12 V
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 4–23
