Tektronix MSO70000 Series

Performance Verification (MSO/DPO5000 Series)
Auxiliary (Trigger) Output
Performance checks
Low limit Test result Hig h lim it
High 1 M Ω
≥ 2.5 V
–
Trigger Output
Low 1 MΩ
–
≤ 0.7 V
High 50 Ω
≥ 1.0 V
–
Trigger Output
Low 50 Ω
–
≤ 0.25 V
4–24 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
