Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical s pecifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.
)
Characteri
stic
Descriptio
n
Pulse response, peak detect, or
envelope mo
de, typical
Sample rate
setting
Minimum pulse width
≤ 10 G S/s 1 ÷ (sample
rate) or 100 ps
40 MS/s 1 ÷ (sampl
e rate) or 25 ps
< 4 GHz mode
ls
This inst
rument uses analog peak detection for pulse capture in Peak Detect or Envelope
mode at sample rates of 125 MS per second and slower. At faster sample rates the instrument
uses conventional sampling.
The mini
mum single pulse widths for 50% or greater amplitude capture for pulses greater than
2 divisions in magnitude.
Effective bits, typical
≥ 4 GHz models
Nine division sine wave input at the indicated frequency, sampled at 500 mV FS and maximum
sample rate
Enhanced bandwidth
MSO72004C,
DSA72004C,
DPO72
004C
MSO71604C,
DSA71604C,
DPO71
604C
MSO71254C,
DSA71254C,
DPO71
254C
MSO70804,
DSA70804B,
DPO70
804B
MSO70604,
DSA70604B,
DPO70
604B
MSO70404,
DSA70404B,
DPO70
404B
20 GHz
Input
frequency
50 GS
/s
100 G
S/s
16 GHz 12.5 G
Hz
8GHz 6GHz 40GHz
10 MHz 5.0 bits 5.3 bits 5.7 bits 5.9 bits 5.7 bits 5.8 bits 6.0 bits
1GHz
5.0 bits 5.3 bits 5.6 bits 5.8 bits 5.7 bits 5.8 bits 5.9 bits
2GHz
4.9 bits 5.2 bits 5.6 bits 5.7 bits 5.7 bits 5.7 bits 5.8 bits
3GHz
4.9 bits 5.2 bits 5.5 bits 5.6 bits 5.5 bits 5.6 bits 5.7 bits
4GHz
4.8 bits 5.1 bits 5.5 bits 5.6 bits 5.5 bits 5.6 bits 5.7 bits
5GHz
4.8 bits 5.1 bits 5.4 bits 5.5 bits 5.5 bits 5.5 bits
6GHz
4.7 bits 5.0 bits 5.3 bits 5.4 bits 5.4 bits 5.4 bits
7GHz
4.3 bits 4.6 bits 5.1 bits 5.5 bits 5.4 bits
8GHz
3.9 bits 4.2 bits 4.4 bits 5.6 bits 5.3 bits
9GHz
3.2 bits 3.5 bits 5.1 bits 5.6 bits
10 GHz
2.8 bits 3.1 bits 5.5 bits 5.6 bits
11 GHz
3.9 bits 4.2 bits 5.4 bits 5.6 bits
12 GHz
4.8 bits 5.1 bits 5.4 bits 5.6 bits
13 GHz
4.5 bits 4.8 bits 5.2 bits
14 GHz
4.4 bits 4.7 bits 5.1 bits
15 GHz
4.5 bits 4.8 bits 5.1 bits
16 GHz
4.5 bits 4.8 bits 5.1 bits
17 GHz
4.4 bits 4.4 bits
18 GHz
4.5 bits 4.5 bits
19 GHz
4.6 bits 4.6 bits
20 GHz
4.8 bits 5.1 bits
