Tektronix MSO70000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.
)
Without enhanced bandwidth
Input
frequency
MSO72004C,
DSA72004C
,
DPO72004C
MSO71604C,
DSA71604C
,
DPO71604C
MSO71254C,
DSA71254C
,
DPO71254C
MSO70804,
DSA70804B
,
DPO70804B
MSO70604,
DSA70604B
,
DPO70604B
MSO70404,
DSA70404B
,
DPO70404B
10 MHz 5.4 bits 5.4 bits 5.6 bits 5.6 bits 5.7 bits 5.8 bits
1GHz
5.4 bits 5.4 bits 5.5 bits 5.6 bits 5.7 bits 5.8 bits
2GHz
5.3 bits 5.3 bits 5.4 bits 5.4 bits 5.6 bits 5.7 bits
3GHz
5.3 bits 5.3 bits 5.4 bits 5.4 bits 5.5 bits 5.6 bits
4GHz
5.2 bits 5.2 bits 5.3 bits 5.3 bits 5.4 bits 5.5 bits
5GHz
5.2 bits 5.2 bits 5.3 bits 5.2 bits 5.3 bits
6GHz
5.0 bits 5.0 bits 5.2 bits 5.2 bits 5.3 bits
7GHz
4.8 bits 4.8 bits 5.1 bits 5.2 bits
8GHz
4.4 bits 4.4 bits 5.0 bits 5.2 bits
9GH
z
4.1 bits 4.1 bits 5.0 bits
10 G
Hz
4.0 bits 4.0 bits 5.1 bits
11
GHz
4.1 bits 4.1 bits 5.2 bits
12
GHz
3.8 bits 3.8 bits 5.1 bits
1
3GHz
4.1 bits 4.1 bits
14 GHz
4.7 bits 4.7 bits
15 GHz
4.7 bits 4.7 bits
16 GHz
4.7 bits 4.7 bits
Effective bits, typical
<4 GHz models
Effective bits for a 450 mV sine wave input at the indicated frequency, sampled at
the given sample rate and BWE settings. All measurements are made at 50 mV/div
with a 20K record length.
DPO7354 3 GHz sine wave leveled to 6 divisions on screen and 3.5 GHz sine wave leveled to
4 divisions on screen due to slew rate limiting.
Enhanced bandwidth
40 GS/s
Analog bandwidth setting
Input
Frequency
3.5 GHz 3.0 G Hz 2.5 G Hz 2.0 GHz 1.0 GHz 0.5 GHz
10 MHz 5.9 bits 6.1 bits 6.2 bits 6.4 bits 6.8 bits 7.1 bits
510 MHz 5.9 b its 6.0 bits 6.1 bits 6.4 bits 6.8 bits 7.1 bits
1010 MHz 5.6 bits 5.7 bits 5.8 bits 6.1 bits 6.8 bits
1510 MHz 5.6 bits 5.8 bits 6.2 bits 6.3 bits
2010 MHz 5.8 bits 6.0 bits 6.1 bits 6.3 bits
2510 MHz 5.7 bits 5.7 bits 5.9 bits
3010 MHz 5.7 bits 5.8 bits
3510 MHz 5.6 bits
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 1–15
