Tektronix MSO70000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.
)
MSO70804,
MSO70604,
MSO70404,
DSA70804B
,
DSA70604B,
DSA70404B,
DPO70804B
,
DPO70604B,
DPO70404B,
where
applicable
8GHz 7GHz 6GHz 5GHz 4GHz 3GHz 2GHz 1GHz
500MHz
Gain setting
10 mV 0.54mV 0.51mV 0.48 mV 0.45mV 0.42 mV 0.40 mV 0.37 mV 0.32 mV 0.24 mV
15 mV 0.73mV 0.69mV 0.64 mV 0.60mV 0.55 mV 0.50 mV 0.46 mV 0.39 mV 0.32 mV
20 mV 0.86mV 0.80mV 0.77 mV 0.72mV 0.68 mV 0.60 mV 0.55 mV 0.46 mV 0.40 mV
30 mV 1.34mV 1.25mV 1.16 mV 1.07mV 0.98 mV 0.89 mV 0.78 mV 0.67 mV 0.57 mV
40 mV 1.67mV 1.58mV 1.50 mV 1.41mV 1.32 mV 1.14 mV 1.01 mV 0.88 mV 0.76 mV
50 mV 1.94mV 1.85mV 1.76 mV 1.67mV 1.58 mV 1.41 mV 1.23 mV 1.01 mV 0.92 mV
60 mV 2.41m
V
2.29m
V
2.17 m
V
2.04m
V
1.91 m
V
1.70 m
V
1.50m
V
1.23m
V
1.10 m
V
70 mV 2.87mV 2.73mV 2.58 mV 2.41mV 2.23 mV 1.99 mV 1.76 mV 1.44 mV 1.28 mV
80 mV 3.34mV 3.17mV 2.99 mV 2.77mV 2.55 mV 2.29 mV 2.02 mV 1.65 mV 1.45 mV
90 mV 3.70
mV
3.56
mV
3.34
mV
3.12
mV
2.90
mV
2.55
mV
2.24
mV
1.89
mV
1.67
mV
100 mV 4.28mV 3.99mV 3.83 mV 3.46mV 3.38 mV 3.00 mV 2.59 mV 2.03 mV 1.65 mV
200 mV 8.36mV 8.09mV 7.48 mV 6.95mV 6.60 mV 5.80 mV 5.08 mV 4.19 mV 3.66 mV
250
mV
10.
23mV
9.8
6mV
9.2
0mV
8.6
1mV
8.1
8mV
7.2
1mV
6.3
2mV
5.2
0mV
4.6
1mV
300 mV 12.10mV 11.62 mV 10.92mV 10.27mV 9.75 mV 8.62 mV 7.55 mV 6.21 mV 5.56 mV
400 mV 16.61mV 15.90mV 14.99mV 14.18 mV 12.97mV 11.50mV 10.07mV 8.28mV 7.50 mV
45
0mV
18
.57mV
17
.75mV
16
.78mV
15
.91mV
14
.55mV
12
.92mV
11
.31mV
9.
29mV
8.
46 mV
500 mV 20.53mV 19.60mV 18.58mV 17.65 mV 16.13mV 14.34mV 12.55mV 10.31mV 9.41 mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 1–25
