Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical s pecifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.
)
MSO72004C,
DSA72004C,
DPO72004C
Enhanced ba
ndwidth, at 100 GS/s. (For all settings below 17 GHz, the noise specifications at 100 GS/s are
the same as for sample rates less than 100 GS/s.)
Gain setting 20 GHz 19 GHz 18 GHz 17 GHz
10 mV
N/A N/A
0.665 mV 0.981 mV
15 mV
N/A N/A
0.8835 mV 0.954 mV
20 mV 1.736 mV 1.4195 mV 1.0355 mV 1.206 mV
30 mV 2.448 mV 1.9975 m
V
1.4195 m
V
1.71 mV
40 mV 3.072 mV 2.635 mV 1.976 mV 2.277 mV
50 mV 2.944 mV 2.635 mV 2.175 mV 2.349 mV
60 mV 3.528 m
V
3.145 m
V
2.641 m
V
2.817 m
V
70 mV 4.12 mV 3.655 mV 3.1065 mV 3.285 mV
80 mV 4.704 mV 4.165 mV 3.572 mV 3.744 mV
90 mV 4.968
mV
4.513
5mV
3.952
mV
4.113
mV
100 mV 8.688 mV 7.095 mV 5.054 mV 7.182 mV
200 mV 15.352 mV 13.209 mV 9.766 mV 11.394 mV
250 m
V
17.3
92 mV
15.1
895 mV
11.6
47 mV
13.3
38 mV
300 mV 19.432 mV 17.17 mV 13.528 mV 15.192 mV
400 mV 23.52 mV 21.131 mV 17.347 mV 19.053 mV
450
mV
25.
56 mV
23.
12 mV
19.
235 mV
20.
961 mV
500 mV 27.6 mV 25.1005 mV 21.1185 mV 22.869 mV
Noise, typical
< 4 GHz models
Nondeterministic fluctuation in the displayed signal.
DPO7354
Enhanced bandwidth
40 GS/s
Step gain 3.5 GHz 3.0 GHz 2.5 GHz 2.0 GHz 1.0 GHz 0.5 GHz
500 mV 23.5 mV 20.2 mV 18.9 mV 16.5 mV 12.2 mV 9.7 mV
200 mV 10.9 mV 9.2 mV 8.1 mV 7.05 mV 5.3 mV 4.1 m V
100 mV 6.6 mV 5.4 mV 4.9 mV 4.2 mV 3.05 mV 2.35 mV
50 mV 2.35 mV 2.1 mV 1.9 mV 1.7 mV 1.3 mV 1.0 mV
20 mV 1.03 mV 0.89 mV 0.811 mV 0.72 m V 0.53 mV 0.43 mV
10 mV 0.61 mV 0.55 mV 0.47 mV 0.42 mV 0.3 mV 0.23 mV
5 mV 0.41 mV 0.415 mV 0.41 mV 0.4 mV 0.21 mV 0.16 mV
2 mV 0.19 mV 0.19 mV 0.19 mV 0.19 mV 0.185 mV 0.185 mV
1 mV 0.12 mV 0.12 mV 0.12 mV 0.12 mV 0.12 mV 0.12 mV
1–26 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
