Specifications (MSO/DPO5000 Series)
Table 2-1: Analog c hannel input and vertical specification (cont.)
Characteristic Description
Full bandwidth, with amplitude tolerance of -3 dB and operating temperatures of ≤30 °C (86 °F).
Reduce the bandwidth by 1% for each °C above 30 °C.
Instrument
SCALE range
Bandwidth
5 mV/div — 10 V/div DC to 500 MHz
2 mV/div — 4.98 mV/div DC to 350 MHz
MSO5204,
DPO5204,
MSO5104,
DPO5104
1 mV/div — 1.99 mV/div DC to 175 MHz
5 mV/div — 10 V/div DC to 500 MHz
2 mV/div — 4.98 mV/div DC to 350 MHz
MSO5054, typical
DPO5054, typical
1 mV/div — 1.99 mV/div DC to 175 MHz
5 mV/div — 10 V/div DC to 350 MHz
2 mV/div — 4.98 mV/div DC to 350 MHz
MSO5034, typical
DPO5034, typical
1 mV/div — 1.99 mV/div DC to 175 MHz
Analog
bandwidth, 1 MΩ,
DC coupled
The MSO/DPO5204 and MSO /DPO 5104 models have separate 50 Ω and 1 MΩ analog paths, so they must
be tested at both settings. All other models have one analog path, so the analog path is fully tested with the
50 Ω termination.
Full bandwidth, with amplitude tolerance of -3 dB and operating temperatures of ≤30 °C (86 °F). Reduce the
bandwidth by 1% for each °C above 30 °C.
Instrument
SCALE range
Bandwidth
50 mV/div — 100 V/div DC to 1 GHz (TPP1000 probe)
DC to 500 MHz (TPP0500 probe)
20 mV/div — 49.8 m V/div DC to 350 MHz
MSO5204,
DPO5204,
MSO5104,
DPO5104
10 mV/div — 19.9 m V/div DC to 175 MHz
50 mV/div — 100 V/div DC to 500 MHz
20 mV/div — 49.8 m V/div DC to 350 MHz
MSO5054,
DPO5054
10 mV/div — 19.9 m V/div DC to 175 MHz
50 mV/div — 100 V/div DC to 350 MHz
20 mV/div — 49.8 m V/div DC to 350 MHz
Analog
bandwidth with
TPP0500 and
TPP1000 probe,
typical
MSO5034,
DPO5034
10 mV/div — 19.9 m V/div DC to 175 MHz
Lower frequency
limit, AC coupled,
typical
< 10 Hz when AC, 1 MΩ coupled
The AC coupled lower frequency limits are reduced by a factor of 10 when 10X passive probes are used.
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 2–5
