Replaceable Parts (DPO7000 Series)
Table 5-6: Repl
aceable parts Drives (DPO7000 Series)
Fig. & index
number
Tektronix
part
number
Serial no.
effective
Serial no.
discont’d Qty Name & descript
ion
5-7
DRIVES
-1 065-0744-00 1
DISK DRIVE ASSY; SERVICE REPLACEMENT W/O SOFTWARE,
W/ PACKAGING
-2 211-1050-00 11
SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
-3 407-5069-0
0
1
BRACKET, RHDD; SATA COMBO CABLE, 3.5 INCH REMOVABLE
HARD DISK DRIVE RECEPTACLE
-4 174-5169-0
0
1
CABLE ASSY; SATA COMBO, HARD DRIVE CABLE
-5
679-5915-00 1
CKT BD SUBA
SSY; DVD-CD/RW ADAPTER, UNTESTED,
389-3689-00 WIRED
-6 129-1618-00 1
SPACER; DV
D-CD/RW SLIMLINE DRIVE ADAPTER, PLASTIC
-7
065-0666-02 1
DISK DRIVE; OPTICAL, 644MB, CD-RW/DVD ROM,
COMBO,16
.7 MB/SEC, IDE/ATAPI; DW-224E-C93, SAFETY
CONTROLLED
-8 211-0950-00 3
SCREW, MA
CHINE; M2X.4X3L, PHL, PNH, STL NI PL
-9 407-5156-00 1
BRACKET, DVD-CD/RW, COMBO; ADAPTER FOR DVD-CD/RW,
COMBO, S
LIMLINE
-10 174-5017-00 1
CABLE ASSEMBLY; DVD POWER
5–14 MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
