Tektronix MSO70000 Series

Replaceable Parts (DSA/DPO70000B Series)
Replaceable P
arts (DSA/DPO70000B Series)
Table 5-7: Re
placeable parts – External 1 (DSA/DPO70000B Series)
Fig. &
index
number
Tektronix
part
number
Serial no.
effective
Serial no.
discont’d Qty Name & description
5-8
EXTERNAL PART S
-1 016-1441-01 1
ACCESSORY POUCH; BLACK CORDURA
-2 200-5065-00 1
COVER,TOP;COSMETIC
-3 211-1224-00 8
SCREW, MACHINE; 6-32 X 0.375, PNH, STL, CDPL, T-15
-4 355-0298-00 1
STUD.SNAP; 0.570 DIA, 0.165 THK, STAINLESS STEEL
-5
200-5066-00 1
COVER; EMI TOP
-6 211-1050-00 14
SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
-7
348-1859-00 4
FOOT; REAR, W/ CORD WRAP, THERMOPLASTIC
-8 101-0173-01 1
TRIM, ACQUISITION INSERT
-9 101-0171-00 1
TRIM RING; FR110, PC/ABS
-10 200-4963-00 1
COVER, F RONT; PC/ABS ALLOY BAYBLEND
-11 101-0174-00 1 TRIM, DVD
335-1940-00 1
MARKER, IDENT; DPO70404B
335-1939-00
MARKER, IDENT; DPO70604B
335-1938-00
MARKER, IDENT; DPO70804B
335-1943-00
MARKER, IDENT; DPO71254B
335-1942-00
MARKER, IDENT; DPO71604B
335-1941-00
MARKER, IDENT; DPO72004B
335-1946-00
MARKER, IDENT; DSA70404B
335-1945-00
MARKER, IDENT; DSA70604B
335-1944-00
MARKER, IDENT; DSA70804B
335-1949-00
MARKER, IDENT; DSA71254B
335-1948-00
MARKER, IDENT; DSA71604B
-12
335-1947-00
MARKER, IDENT; DSA72004B
-13 348-1817-00 2
FOOT, SKID
5–16 MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
