Tektronix MSO70000 Series

Replaceable Parts (MSO70000/C, DSA/DPO70000C Series)
Table 5-16: Rep
laceable parts – External 2 (MSO70000/C, DSA/DPO70000C Series)
Fig. &
index
number
Tektronix
part
number
Serial no.
effective
Serial no.
discont’d Qty Name & description
5-18-
EXTERNAL PARTS
-1 174-5226-00 1
CABLE ASSY; LINE FILTER
-2 211-1050-00 16
SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
200-5123-00 1
COVER; EMI BOTTOM, MSO70804/70604/70404
200-5124-00 1
COVER; EMI BOTTOM, MSO72004/71604/71254
-3
200-5171-00 1
COVER; EMI BOTTOM, MSO72004C, MSO71604C, MSO71254C,
DSA72004C, DSA71604C, DSA71254C, DPO72004C, DPO71604C,
DPO71254C,
-4 200-5125-00 1
COVER, BOTTOM; COSMETIC; W/FEET
-5
212-0232-00 2
SCREW,MACHINE; 8-32 X 1.125L, PNH, STL, BLACK ZINC SPEC
#ASTM B633 TYPE II, T-20
367-0528-00 1
HANDLE, CARRYING; DUAL DUROMETER MOLDED,
POLYPROPYLENE, VINYL GRIP SECTION
-6
407-4887-00 1
BRACKET; HANDLE BASE, PC/ABS ALLOY, BAYER BAYBLEND FR-110,
TEK BLUE
-7
348-1951-00 1
FRONT FOOT ASSEMBLY, FLIP (2), SAFETY CONTROLLED
-8 211-1224-00 2
SCREW, MACHINE, BLACK
5–34 MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
