Tektronix MSO70000 Series

Replaceable Parts (MSO70000/C, DSA/DPO70000C Series)
Replaceable P
arts (MSO70000/C, DSA/DPO70000C Series)
Table 5-15: R
eplaceable parts – External 1 (MSO70000/C, DSA/DPO70000C Series)
Fig. &
index
number
Tektronix
part
number
Serial no.
effective
Serial no.
discont’d Qty Name & description
5-17-
EXTERNAL PART S
-1 016-1441-01 1
ACCESSORY POUCH; BLACK CORDURA
-2 200-5119-00 1
COVER,TOP;COSMETIC
-3 211-0967-00 2
SCREW; 6-32X 0.25,PNH,T-15, W/FLAT WASHER, STEEL, ZINC FINISH
-4 355-0298-00 1
STUD.SNAP; 0.570 DIA, 0.165 THK, STAINLESS STEEL
-5
200-5060-00 1
COVER; EMI TOP
-6 211-1050-00 19
SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
-7
348-1859-00 4
FOOT; REAR, W/ CORD WRAP, THERMOPLASTIC
-7a
211-0721-00 4
SCREW, MACHINE; 6-32 X 0.375, PNH, STEEL, ZINC FINISH WITH
NYLOC PATCH, T-15
-8 101-0173-01
101-0184-00
1
1
TRIM, ACQUISITION INSERT, MSO70000
TRIM, ACQUISITION INSERT MSO70000C, DSA70000C, DPO70000C
-9 101-0171-00 1
TRIM RING; FR110, PC/ABS
-10 200-4963-00 1
COVER, F RONT; PC/ABS ALLOY BAYBLEND
-11 101-0174-00 1 TRIM, DVD
335-2169-00 1
LABEL, NOMENCLATURE, MSO70404
335-2170-00 1
LABEL, NOMENCLATURE, MSO70604
335-2171-00 1
LABEL, NOMENCLATURE, MSO70804
335-2172-00 1
LABEL, NOMENCLATURE, MSO71254
335-2173-00 1
LABEL, NOMENCLATURE, MSO71604
335-2174-00 1
LABEL, NOMENCLATURE, MSO72004
335-2426-00 1
LABEL, NOMENCLATURE, MSO71254C
335-2427-00 1
LABEL, NOMENCLATURE, MSO71604C
335-2428-00 1
LABEL, NOMENCLATURE, MSO72004C
335-2438-00 1
LABEL, NOMENCLATURE, DSA71254C
335-2439-00 1
LABEL, NOMENCLATURE, DSA71604C
335-2440-00 1
LABEL, NOMENCLATURE, DSA72004C
335-2432-00 1
LABEL, NOMENCLATURE, DPO71254C
335-2433-00 1
LABEL, NOMENCLATURE, DPO71604C
-12
335-2434-00 1
LABEL, NOMENCLATURE, DPO72004C
-13 211-0721-00 4
SCREW, MACHINE; 6-32 X 0.375, PNH, STEEL, ZINC FINISH WITH
NYLOC PATCH, T-15 TORX DR
5–32 MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
