Tektronix MSO70000 Series

Replaceable Parts (MSO70000/C, DSA/DPO70000C Series)
Table 5-19: Replaceable parts – Drive bay 2 (MSO70000/C, DSA/DPO70000C Series)
Fig. & index
number
Tektronix
part
number
Serial no.
effective
Serial
no.
discont’d Qty Nam e & description
5-21- DRIVE BAY 2
065-0844-00 1
DRIVE ASSEMBLY,WITH PACKAGING;6505284XX,PRGM HDD ASSY
WITH OS/APPS SW ON HIDDEN PARTITION, FOR ADVANTECH
AIMB-566 MO
THERBOARD;MSO70000
-1
065-0844-01 1
DRIVE ASSEMBLY, WITH PACKAGING;6505284XX,PRGM
HDD ASSY WI
TH OS/APPS SW ON HIDDEN PARTITION, FOR
ADVANTECH AIMB-566 MOTHERBOARD:MSO7000
-2 211-0722-00 8
SCREW, MAC
HINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
174-5169-00 1
CABLE ASSY; SATA COMBO, HARD DRIVE CABLE
-3
174-5349
-00
1
CABLE ASSY; SATA COMBO, HARD DRIVE CABLE
-4 174-5650-00 1
CABLE ASS
Y; SATA-DVD, DATA, AND POWER
-5
211-0950-00 4
SCREW, MACHINE; M2X.4X3L, PHL, PNH, STL NI PL
-6 407-515
6-00
1
BRACKET, DVD-CD/RW; ADAPTER FOR DVD-CD/RW SLIMLINE
-7
065-0807-00 1
DISK DRI
VE; OPTICAL, 644MB, CD-RW/DVD ROM, COMBO,
16.7 MB/SEC, IDE/ATAPI; DW-224E-C93
5–40 MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
