Replaceable Parts (MSO70000/C, DSA/DPO70000C Series)

Table 5-23: Rep

laceable parts – MSO module (MSO70000/C Series)

Fig. &

index

number

Tektronix

part

number

Serial no.

effective

Serial no.

discont’d Qty Name & description

5-25-

MSO Module

-1 407-5448-00 1

BRACKET, FAN, PWR DIST PCB

-2 211-1050-00

SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15

-3 174-5517-00 1

CABLE ASSY;PCIe, STRAIGHT CONNECTOR ON BOTH ENDS,

SAFETY CONTROLLED

-2 119-7036-00 1

FAN ASSEMBLY; DC,12V;0.105A,8.6 CFM,30DBA,3 LEAD, TACH

OUTPUT, WITH CONN & HOUSING,SAFETY CONTROLLED

-4

-------

MSO MODULE, RETURN TO TEKTRONIX FOR SERVICE

-5

174-5516-00 1

CABLE, POWER, 2X4 WITH MINIFIT JR CONNS, SAFETY

CONTROLLED

5–48 MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
