Tektronix MSO70000 Series

Replaceable Parts (MSO70000/C, DSA/DPO70000C Series)
Table 5-24: Rep
laceable parts – μATX 1 (MSO70000/C, DSA/DPO70000C Series)
Fig. &
index
number
Tektronix
part
number
Serial no.
effective
Serial no.
discont’d Qty Name & description
5-26- μATX 1
-1 174-5629-00 1
CABLE, LVDS VIDEO WITH 2X20 HIROSE CONNECTORS;PCIe J18
to μATX LVDS1
-2 174-5763-00 1
CABLE, SATA TO E-SATA, DATA ONLY; RP e-SATA to μATX SATA 2
-3 441-2585-00 1
BRACKET, IO M-BOARD, AMB566, SAFETY CONTROLLED
**ATTACHING PARTS**
211-1050-00 10
SCREW, MACHINE; 6-32 X 0.312 L, PNH, STEEL, ZINC FINISH, T15
214-3903-01 6
SCREW, JACK; 4-40 X 0.312 EXT THD, 4-40 INT THD, 0.188 HEX, ZINC
PLATED STEEL
**END ATTACHING PARTS**
5–50 MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
