Tektronix MSO70000 Series Service Manual

Troubleshooting (DPO7000 Series, MSO70000/C Series, DSA/DPO70000B/C Series)
Table 4-11: 039-0173-xx and 065-0745-xx μATX POST codes (cont.)
Item no. Module
Displayed POST
code Description
5A
Resetting PATA/SATA bus and all devices
6
ATA/ATAPI/SATA
5B
Reserved for ATA
5C Resetting SMBUS
7
SMBus
5D
Reserved for SMBUS
I went on Monday
70
Resetting the VGA controller
71
Disabling the VGA controller
8
Local Console
72
Enabling the VG A controller
78 Resetting the console controller
79 Disabling the console controller
9
Remote Console
7A Enabling the console controller
90 Resetting keyboard
91 Disabling keyboard
92
Detecting presence of keyboard
93 Enabling keyboard
94
Clearing keyboard input buffer
10
Keyboard (PS2 or
USB)
95
Instructing keyboard controller to run Self Test (PS2 only)
98 Resetting mouse
99 Disabling mouse
9A
Detecting presence o f mouse
11
Mouse (PS2 or USB)
9B Enabling mouse
B0
Resetting fixed media
B1
Disabling fixed media
B2
Detecting presence of a fixed media (IDE hard drive detection etc.)
12 Fixed Media
B3
Enabling/configuring a fixed media
B8 Resetting removable media
B9 Disabling removable m edia
BA
Detecting presence of a removable m edia (IDE, CD-ROM
detection, etc.)
13 Removable media
BC Enabling/configuring a removable media
14
BDS
Dy
Trying boot selection y (y=0 to 15)
E0
Started dispatching PEIMs (emitted on
first report of EFI_SW_PC_INIT_BEGIN
EFI_SW_PEI_PC_HANDOFF_TO_NEXT
E2
Permanent memory found
15
PEI Core
E1, E3
Reserved for PEI/PEIMs
MSO70000/C, DSA70000B/C, DPO70000B/C, D PO7000, MSO5000, DPO5000 Series 4–29
