Tektronix RSA306 Technical Reference

Performance ver
ification
8. On the R SA306, peak the m arker on the signal at the center frequency; measure and record the amplitude.
9. Measure and record the power meter amplitude.
10. Repeat steps 6 through 8 for all of the +20 dBm reference level frequencies in the table, measuring power meter
amplitude and RSA306 amplitude.
11. Set the signal generator output amplitude to +1 dBm for the 0 dBm reference level tests. RF amplitude at the power
sensor and the RSA306 = –5 dBm nominal.
12. Repeat steps 6 through 8 for all of the +0 dBm reference level frequencies in the table, measuring power meter amplitude
and RSA306 amplitude. Enter the v alues in the 0 dBm accuracy table. (See Table 6.)
13. Set the signal generator output amplitud
eto–12 dBm for the –13 dBm reference level tests. RF amplitude at the power
sensor and the RSA306 = –18 dBm nominal.
14. Repeat steps 6 through 8 for all of the –13 dBm reference level frequencies in the table, measuring power meter
amplitude and RSA306 amplitude. Enter the values in the –13 dBm accuracy table. (See Table 7 .)
15. Set the signal generator output amplitude to –29 dBm for the –30 dBm reference level tests. RF amplitude at the power
sensor and the RSA306 = –35 dBm nominal.
16. Repeat steps 6 through 8 for all of the –30 dBm reference level frequencies in the table, measuring power meter
amplitude and RSA306 amplitude. Enter the values in the –30 dBm accuracy table. (See Table 8 .)
17. Calculate the amplitude errors for each frequency of each reference level accuracy table. Error = RSA306 measurement
– power meter measurement. Readings are in dBm, error is in dB.
18. Note the largest positive and negative errors in the Error column
in all the reference level measurement tables.
19. Enter these values in the Amplitude accuracy results table. (See Table 9.)
20. Compare the +peak and –peak errors against the specifications.
21. Enter pass or fail in the test record.
Table 5: Amplitude accuracy, +20 dBm reference level measurements
Center/signal
frequency
RSA306 reading,
dBm
Power meter value,
dBm
Error (RSA306 –
Pwr meter), dB
9kHz
20 kHz
50 kHz
100 kHz
300 kHz
1MHz
3MHz
10 MHz
20 MHz
22 MHz
100 MHz
699 MHz
17 RSA306 Speci fications and Performance Verification
