Tektronix TBS1000 Series User Manual

Appendix A: Exam ple of a Vertical Position Accuracy Test Spreadsheet
Table A-1: Vertical position accuracy test spreadsheet (cont.)
34 0.72 0.72 0.724 -0.004 -0.0172 0.0172 0.013
35 0.68 0.68 0.683 -0.003 -0.0168 0.0168 0.014
36 0.64 0.64 0.643 -0.003 -0.0164 0.0164 0.013
37 0.60 0.6 0.6 0.000 -0.016 0.016 0.016
38 0.56 0.56 0.561 -0.001 -0.0156 0.0156 0.015
39 0.52 0.52 0.521 -0.001 -0.0152 0.0152 0.014
40 0.48 0.48 0.481 -0.001 -0.0148 0.0148 0.014
41 0.44 0.44 0.44 0.000 -0.0144 0.0144 0.014
42 0.40 0.4 0.401 -0.001 -0.014 0.014 0.013
43 0.36 0.36 0.361 -0.001 -0.0136 0.0136 0.013
44 0.32 0.32 0.32 0.000 -0.0132 0.0132 0.013
45 0.28 0.28 0.281 -0.001 -0.0128 0.0128 0.012
46 0.24 0.24 0.244 -0.004 -0.0124 0.0124 0.008
47 0.20 0.2 0.204 -0.004 -0.012 0.012 0.008
48 0.16 0.16 0.163 -0.003 -0.0116 0.0116 0.009
49 0.12 0.12 0.123 -0.003 -0.0112 0.0112 0.008
50 0.08 0.08 0.083 -0.003 -0.0108 0.0108 0.008
51 0.04 0.04 0.043 -0.003 -0.0104 0.0104 0.007
52 0.00 0 0.002 -0.002 -0.01 0.01 0.008
53 -0.04 -0.04 -0.039 -0.001 -0.0104 0.0104 0.009
54 -0.08 -0.079 -0.079 0.000 -0.01079 0.01079 0.011
55
-0.12 -0.12 -0.118 -0.002 -0.0112 0.0112 0.009
56 -0.16 -0.159 -0.159 0.000 -0.01159 0.01159 0.012
57
-0.20 -0.199 -0.198 -0.001 -0.01199 0.01199 0.011
58 -0.24 -0.239 -0.238 -0.001 -0.01239 0.01239 0.011
59 -0.28 -0.279 -0.274 -0.005 -0.01279 0.01279 0.008
60 -0.32 -0.319 -0.314 -0.005 -0.01319 0.01319 0.008
61 -0.36 -0.359 -0.353 -0.006 -0.01359 0.01359 0.008
62 -0.40 -0.399 -0.393 -0.006 -0.01399 0.01399 0.008
63 -0.44 -0.439 -0.432 -0.007 -0.01439 0.01439 0.007
64 -0.48 -0.48 -0.473 -0.007 -0.0148 0.0148 0.008
65 -0.52 -0.52 -0.513 -0.007 -0.0152 0.0152 0.008
66 -0.56 -0.56 -0.552 -0.008 -0.0156 0.0156 0.008
67 -0.6 -0.6 -0.592 -0.008 -0.016 0.016 0.008
68 -0.64 -0.64 -0.633 -0.007 -0.0164 0.0164 0.009
69 -0.68 -0.68 -0.673 -0.007 -0.0168 0.0168 0.010
70 -0.72 -0.72 -0.713 -0.007 -0.0172 0.0172 0.010
71 -0.76 -0.76 -0.754 -0.006 -0.0176 0.0176 0.012
TBS1000 Series Oscilloscope Service Manual A-3
