Specifications
Mechanical Ch
aracteristics
Table 1-8: Mechanical characteristics
Characteris
tic
Description
Weight
Requirement
s that follow are nominal:
2.0 kg (4.4 lbs), stand-alone instrument
2.2 kg (4.9 lbs), with accessories
3.6kg(8lbs
), when packaged for domestic shipment
Height
158 mm (6.2
2in)
Width
326.3 mm ( 1
2.85 in)
Size
Depth
124.1 mm (
4.88 in)
Cooling
Method
Convect
ion cooled
Environmental Performance
Table 1-9: Environmental performance
Characteristic Description
Operating 0° C to +50° C (32 °F to 122 °F), with 5° C/minute m aximum gradient,
nonco
ndensing, up to 3000 m altitude
Temperature
Nonoperating
–40°
C to +71° C (–40 °F to 159.8 °F), with 5° C/minute maximum gradient
Oper
ating
5% to
85% relative humidity (% RH) at up to +40° C
5% to 45% RH above +40° C up to +50° C, noncondensing, and as limited
by a Maximum Wet-Bulb Temperature of +37° C (derates relative humidity
to 4
5 % RH at +50° C)
Humidity
Nonoperating
5% t
o 85% relative humidity (% RH) at up to +40° C
5% to 45% RH above +40° C up to +50° C, noncondensing.
Above +50° C limited by a Maximum Wet-Bulb Temperature of +37° C
(d
erates relative humidity to 12% RH at +71° C)
Op
erating
Up
to 3000 meters (10,000 feet)
Altitude
Nonoperating
U
p to 3000 meters (10,000 feet).
Altitude is limited by possible dam age to the LCD at higher altitudes. T his
damage is independent of operation
Data Logging System Characteristics
NOTE. This software feature directs the oscilloscope to automatically collect
data over a period of tim e. After you configure the trigger conditions to use,
you can use the data logging menu to set up the oscilloscope so that it will save
all of the triggered waveform to a USB memory device, within a time duration
that you have set.
1–14 TBS1000 Series Oscilloscope Service Manual
