Tektronix TBS1000 Series User Manual

Maintenance
Troubleshooting
This section contains information and procedures to help you isolate a defective
module in the oscilloscope.
WARNING. Before performing this or any other procedure in this manual, read the
General Safety Summary and Service Safety Summary found at the beginning of
this manual
. A lso, to prevent possible injury or damage to electrical components,
read Preventing ESD. (See page 6 -1, Preventing ESD.)
Adjustment After Repair
If you replace the Main board or power supply, you must adjust the oscilloscope
after repair. Refer to the chapter Adjustment Procedures.
Required Tools and
Equipment
Use the f
ollowing tools and equipment to troubleshoot the oscilloscope:
Table 6-3: Tools and equipment
Tools and equipment Example
Oscilloscope with 1X/10X and 100X
probes
Tektronix TBS1000 series oscilloscope with standard accessory 10X probe (TPP0201 or
TPP0101) and optional 100X probe (P5100 or P5200)
DMM 3.5 or greater digit DMM
USB flash drive
Tektr
onix part number 119-7276-00, 128 MB
USB type A to type B cable Tektronix par t numbers: 174-4401-00, 0.91 meters (3 feet) 174-5194-00, 1.83 meters (6 feet)
PC with USB host post and
with TekVISA (OpenChoice PC
Comm
unications) installed
PC with USB communication port
Troubleshooting Tree
To i
solate a problem to a specific troubleshooting procedure, use the
troubleshooting tree that is shown on the next four pages. Detailed procedures
follow the tree.
6–22 TBS1000 Series Oscilloscope Service Manual
