Tektronix TBS1000 Series User Manual

Specifications
Ta ble 1-1: Signal ac q uis i tion syste m char acteristics (cont.)
Characteristic
Description
This is the lower frequency for Analog Bandwidth when the instrument is AC-coupled
Lower- Frequency Limit,
AC Coupled
≤ 10 Hz.
<1 Hz when 10X, passive probes are used.
Model
Expected full bandwidth rise time
TBS1154, TBS1152
2.6 ns
TBS1104, TBS1102
3.5 ns
TBS1064, TBS1062
6.0 ns
TBS1042
8.8 ns
TBS1022
14.0 ns
Rise Time, typical
Rise time is generally calculated from the following formula: Rise time in ns = 350 / Bandwidth in MHz
This is the capability of the instrument to capture single event pulses using the Peak Detect Acquisition
Mode.
The minimum single pulse widths for guaranteed 50% or greater amplitude capture are as follows:
Model
Sec/Div Setting
Minimum Pulse Width
TBS1154
TBS1152
TBS1104
TBS1102
TBS1064
TBS1062
50 sec/div to 5 μS/div
12 ns
Peak Detect Mode Pulse
Response
TBS1042
TBS1022
50 sec/div to 5 μS/div
13 ns
These a re the ranges of the user-settable input offset voltage.
Volts/Div Setting
Position Range
2 mV/div to 200 mV/div
±1.8V
Vertical Position Ranges
> 200 mV/div to 5 V /div
±45V
This is the accuracy of the nominal voltage level represented by the code at the vendor of the A-D
converter's dynamic range.
Volts/Div Setting
Position Accuracy
2 mV/div to 200 mV/div ±(1% of |selected v alue| + 0.1 div + 5 mV) within the
range ±1.8 V
√ Vertical Position
Accuracy
> 200 mV/div to 5 V/div ±(1% of |selected value| + 0.1 div + 125 mV) w ithin the
range ±45 V
TBS1000 Series Oscilloscope Service Manual 1–5
