Specications
Table 1-3: Triggering system (cont.)
Characteristic Description
AC, DC, Noise Reject, High Frequency Reject, Low Frequency RejectTrigger Coupling
The External Trigger path does not have a DC blocking capacitor ahead of the trigger input circuit. The
rolloff associated with AC coupling happens after the input circuit. When attempting to trigger on an AC
signal that has a DC offset, care must be used to avoid overloading the input of the External Trigger
circuit. For signals that have a large DC offset, using Channel 1 or Channel 2 (and Channel 3 or Channel
4 for the TBS1154, TBS1104, and TBS1064) with AC coupling is preferred.
Trigger Slope
Rising Edge, Falling Edge
Measurement Style A) The minimum signal levels for achieving stable frequency indication on the Trigger
Frequency Counter within 1% of correct indication.
Measurement Style B) Section 4 10.2 in IEEE Std. #1057. The m inimum signal levels required for stable
edge triggering of an acquisition when the trigger Source is DC coupled.
Trigger Source Sensitivity (Measurement
style A), typical
Sensitivity (Measurement
style B)
Channel Inputs
All products
1.5 div from DC to
10MHz(>2mV/div)
4 div from DC to 10 MH z
(2 mV/Div)
1 div from DC to 10 MHz >
2 mV/div)
2.5 div from DC to 10 MHz
(2 mV/Di v)
TBS1154,
TBS1152
3 div between 10 MHz
and 150 MHz
1.5 div between 10 MHz and
100 MHz
2.0 div above 100 MHz to
150 MHz
TBS1104,
TBS1102
3 div between 10 MHz
and 100 MHz
1.5 div between 10 MHz and
100 MHz
TBS1064,
TBS1062
3 div between 10 MHz
and 60 MHz
1.5 div between 10 MHz and
60 MHz
TBS1042
3 div between 10 MHz
and 40 MHz
1.5 div between 10 MHz and
40 MHz
TBS1022
3 div between 10 MHz
and 25 MHz
1.5 div between 10 MHz and
25 MHz
All products
300 mV from DC to
100 MHz
200 mV from DC to 100 MHz
Ext
TBS1154,
TBS1152
500 mV from 100 MHz to
150 MHz
350 mV from 100 MHz to
150 MHz
All products
1.5 V from DC to 100 MHz 1 V from DC to 100 MHz
Ext/5
TBS1154,
TBS1152
2.5 V from 100 MHz to
150 MHz
1.75 V from 100 MHz to
150 MHz
Sensitivity,
Edge-Ty pe Trigger,
DC Coupled
Trigger Frequency Readout typically stabilizes at 50% more signal than generates a stable visual display.
TBS1000 Series Oscilloscope Service Manual 1–9
