Specifications
Table 1-11: Limit testing system characteristics (cont.)
Characteristic Description
Destination Ref Channel The location of the reference memory location that is used to store the limit test template.
RefA, RefB.
Ref C and RefD are available on 4-channel models.
Display Template Displays or does not display a stored test template.
On, Off.
Action on Violation
Defines the actions the oscilloscope will take after a violation is detected.
Save Image: The oscilloscope will automatically sa ve a screen image when a violation is detected.
Save Waveform: The oscilloscope will automatically save a digital copy of the source waveform when
a violation is detected.
Stop After Defines the conditions that will cause the oscilloscope to end limit testing.
Manual: Lets you stop the test by toggling the “Run/stop” choice.
Waveforms: Lets you set the numbers of waveforms to test before stopping limit testing.
Violations: Lets you set the numbers of violations to detect before stopping limit testing.
Elapsed time: Lets you set the elapsed test time in seconds to pass before stopping limit testing.
1–16 TBS1000 Series Oscilloscope Service Manual
