Tektronix TBS1052B User Manual

Waveform math
Arithmetic Add, Subtract, Multiply
Math functions FFT
FFT Windows: Hanning, Flat Top, Rectangular 2048 sample points
Sources Two channel models: CH1 - CH2, CH2 - CH1, CH1 + CH2, CH1 × CH2
Autoset
Autoset menu Single-button, automatic setup of all channels for vertical, horizontal, and trigger systems, with
undo Autoset
Square wave Single Cycle, Multicycle, Rising or Falling Edge
Sine wave Single Cycle, Multicycle, FFT Spectrum
Video (NTSC, PAL, SECAM) Field: All, Odd, or Even Line: All or Selectable Line Number
Autorange
Automatically adjust vertical and/or horizontal oscilloscope settings when probe is moved from
point to point, or when the signal exhibits large changes.
Specifications
TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual 119

Tektronix TBS1052B Specifications

General

Bandwidth	50 MHz
Channels	2
Sample Rate	1 GS/s
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Interfaces	USB 2.0
Record Length	2.5 kpts
Display	7-inch WVGA (800 x 480)
Trigger Types	Edge, Pulse Width
Display Type	Color LCD
Display Resolution	800 x 480
Input Impedance	1 MΩ
Power Supply	100 to 240 V
