Tektronix TBS1052B User Manual

Power source
Power source voltage 100 to 240 V ±10%
Power source frequency
100 V to 240 V 50 Hz to 60 Hz
115 V 400 Hz ±10%
Power consumption 30 W maximum
Physical characteristics
Dimensions
mm in.
Height 158.0 6.22
Width 326.3 12.85
Depth 124.2 4.89
Shipping dimensions
mm in.
Height 266.7 10.5
Width 476.2 18.75
Depth 228.6 9.0
Weight
kg lb.
Instrument only 2.0 4.3
...with accessories 2.2 4.9
RM2000B rackmount
mm in
Width 482.6 19.0
Height 177.8 7.0
Depth 108.0 4.25
Specifications
TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual 121

Tektronix TBS1052B Specifications

General

Bandwidth	50 MHz
Channels	2
Sample Rate	1 GS/s
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Interfaces	USB 2.0
Record Length	2.5 kpts
Display	7-inch WVGA (800 x 480)
Trigger Types	Edge, Pulse Width
Display Type	Color LCD
Display Resolution	800 x 480
Input Impedance	1 MΩ
Power Supply	100 to 240 V
