TDS 200-Series Digital Oscilloscope User Manual
1
Getting Started
TDS 200-Series Digital Oscilloscopes are small, lightweight,
benchtop packages that you can use to take ground-referenced
measurements. The TDS 210 and TDS 220 oscilloscopes have
two-channels; the TDS 224 has four channels.
In addition to the list of general features, this section covers the
following topics:
H How to install your product
H How to add extended functions
H How to perform a brief functional check
H How to compensate probes
H How to use the self calibration routine
H How to match your probe attenuation factor
NOTE. To select a display language, push the UTILITY menu button,
and then push the Language menu box item to select the appropriate
language.
