TDS 200-Series Digital Oscilloscope User Manual
Waveforms
Menu Settings Comments
Waveforms Highlighting Waveforms displays the
menus for storing or recalling waveforms
Source CH1
CH2
CH3*
CH4*
Math
Choose the waveform display to store
Ref A
B
C*
D*
Choose the reference location to store or
recall a waveform
Save Stores source waveform to the chosen
reference location
Ref(x) ON
OFF
Turns the reference waveform display on
or off
* Only available on the TDS 224 oscilloscope.
Saving and Recalling Waveforms. For the TDS 210 and TDS 220
oscilloscopes, you can store two reference waveforms in nonvolatile
memory. For the TDS 224 oscilloscope, you can store four reference
waveforms, although you can only display two at a time. You can
display reference waveforms simultaneously with current waveform
acquisitions.
Recalled waveforms are not adjustable.
