Tektronix TDS2014 User Manual

TDS2CMA Communications Module
TDS1000/2000-Series Digital Oscilloscope User Manual
145
2. On the oscilloscope, push UTILITY
" Options " GPIB Setup.
3. Push the Address option button to assign a unique address to the
oscilloscope.
4. Push the Bus Connection option button to have the oscillosc ope
start or stop using the GPIB bus.
Option
Settings Comments
Address 0... 30 Sets oscilloscope GPIB bus address
Bus Connection Talk-Listen, Off-Bus Select Talk-Listen to start oscillo-
scope GPIB bus communications.
Select Off-Bus tostop oscilloscope
GPIB bus communications.
NOTE. The oscilloscope stores these settings until you change them,
even if you push the DEFAULT SETUP button.
Testing the GPIB Interface
To test the oscilloscope GPIB interface, you will need to refer to the
documentation that came with your controller.

Tektronix TDS2014 Specifications

General

Channels	4
Bandwidth	100 MHz
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Display	5.7 inch color LCD
Trigger Types	Edge, Video
Interface	USB
Input Impedance	1 MΩ
Power Requirements	100 to 240 V
