Appendix A: Specificati ons
TDS1000/2000-Series Digital Oscilloscope User Manual
159
Oscilloscope Specifications (Cont.)
Pulse Width Trigger
Pulse Width Trigger
modes
Trigger when < (Less than), > (Greater than), = (Equal), or ≠
(Not Equal); Positive pulse or Negative pulse
Pulse Width Trigger
Point
Equal: The oscilloscope triggers when the trailing edge of the
pulse crosses the trigger level.
Not Equal: If the pulse is narrower than the specified width, the
trigger point is the trailing edge. Otherwise, the oscilloscope
triggers when a pulse continues longer than the time specified as
the Pulse Width.
Less than: The trigger point is the trailing edge.
Greater than (also called time-out trigger): The oscilloscope
triggers when a pulse continues longer than the time specified as
the Pulse Width.
Pulse Width Range Selectablefrom33nsto10s
Pulse Width 16.5 ns or 1 part per thousand, whichever is larger
Equal Guardband t > 330 ns: ±5% ≤ guardband < ±(5.1% + 16.5 ns)
t ≤ 330 ns: guardband = ±16.5 ns
Not Equal Guardband t ≤ 330 ns: guardband = ±16.5 ns
165 ns < t ≤ 330 ns: guardband = --16.5 ns/+33 ns
t ≤ 165 ns: guardband = ±16.5 ns

Tektronix TDS2014 Specifications

General

Channels	4
Bandwidth	100 MHz
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Display	5.7 inch color LCD
Trigger Types	Edge, Video
Interface	USB
Input Impedance	1 MΩ
Power Requirements	100 to 240 V
