TDS3000B Series Service Manual
1-1
Specifications
This appendix contains specifications for t he TDS3000B Series oscilloscopes.
All specifications are guaranteed unless noted as “typical.” Typical specifications
are provided for your convenience but are not guaranteed. Specifications that are
marked with the n symbol are checked in Performance Verification.
All specifications apply to all TDS3000B models unless noted otherwise.
To meet specifications, two conditions must first be met:
H The oscilloscope must have been operating continuously for twenty minutes
within the operating temperature range specified.
H You must perform the C ompensate Signal Path operation described on
page 2--22 prior to evaluating specifications. If the operating temperature
changes by more than 10 °C, you must perform the Compensate Signal Path
operation again.
Table 1- 1: Specifications
Acquisition
Acquisition modes Sample (Normal), Peak detect, Envelope, and Average
Single Sequence Acquisition mode Acquisition stops after
Sample, Peak Detect One acquisition, all channels
simultaneously
Average, Envelope N acquisitions, all channels
simultaneously, N is settable from
2to256(or∞ for Envelope)
