Specifications
1-2
TDS3000B Series Service Manual
Table 1- 1: Specifications (cont.)
Inputs
Input coupling DC, AC, or GND
Channel input remains terminated when using GND coupling.
Input impedance,
DC coupled
1MΩ ±1% in parallel with 13 pF ±2 pF, TekProbe compatible
50 Ω ±1%; VSWR 1.5:1 from DC to 500 MHz, typical
Maximum voltage at Overvoltage category Maximum voltage
g
input BNC (1 MΩ)
CAT I Environment
(refer to page 1--11)
150 V
RMS
(400 V
pk
)
CAT II Environment
(refer to page 1--11)
100 V
RMS
(400 V
pk
)
For steady-state sinusoidal waveforms, derate at 20 dB/decade above
200kHzto13V
pk
at 3 MHz and above.
Maximum voltage at
input BNC (50 Ω)
5V
RMS
with peaks ≤±30 V
Maximum floating
voltage
0 V from chassis (BNC) ground to earth ground, or
30 V
RMS
(42 V
pk
) only under these conditions: no signal voltages
>30 V
RMS
(>42 V
pk
), all common leads connected to the same voltage,
no grounded peripherals attached
Channel-to-channel
crosstalk, typical
Measured on one channel, with test signal applied to another channel,
and with the same scale and coupling settings on each channel
,
y
p
Frequency range Crosstalk
100 MHz 100:1
200 MHz 50:1
300 MHz 50:1
400 MHz 30:1
500 MHz 30:1
600 MHz 30:1
Differential delay,
typical
100 ps between any two channels with the same scale and coupling
settings
