Tektronix TDS3054B

Specifications
TDS3000B Series Service Manual
1-3
Table 1- 1: Specifications (cont.)
Vertical
Number of channels TDS30x2B TDS30x4B
2 plus external trigger input 4 plus external trigger input
Digitizers 9-bit resolution, separate digitizers for each channel sample
simultaneously
SCALE Range 1MΩ 50 Ω
g
(at BNC)
1mV/divto10V/div 1mV/div to 1 V/div
Fine SCALE Adjustable with ≥ 1% resolution
Polarity Normal and Invert
Position range ±5 divisions
n Analog
bandwidth, 50 Ω
(
l
i
l
M
Bandwidth limit set to Full, operating ambient ≤30 °C, derate 1%/°C
above 30 °C
,
(also typical at 1 MΩ
with standard probe)
Scale range
5mV/divto
1V/div
2mV/divto
4.98 mV/div
1mV/divto
1.99 mV/div
TDS301xB 100 MHz 100 MHz 90 MHz
TDS302xB 200 MHz 200 MHz 150 MHz
TDS303xB 300 MHz 250 MHz 150 MHz
TDS304xB 400 MHz 250 MHz 150 MHz
TDS305xB 500 MHz
1
300 MHz
1
175 MHz
1
TDS306xB 600 MHz
1,2
300 MHz
1
175 MHz
1
Calculated rise
t
i
t
i
l
TDS301xB 3.5 ns
time, typical
TDS302xB
1.75 ns
TDS303xB 1.2 ns
TDS304xB 0.9 ns
TDS305xB 0.7 ns
TDS306xB 0.6 ns
1
Values typical for 1 mV/div through 9.98 mV/div.
2
500 MHz typical at 5 mV/div to 9.98 mV/div; 600 MHz at 10 mV/div and greater.
