Specifications
1-10
TDS3000B Series Service Manual
Table 1- 1: Specifications (cont.)
EMC certifications and compliances
EMC Compliance:
European Union
Meets the intent of Directive 89/336/EEC for Electromagnetic
Compatibility. Compliance was demonstrated to the following
specifications as listed in the Official Journal of the European
Communities:
EN 61326
EMC requirements for Class A electrical equipment for
measurement, control, and laboratory use
1,2
IEC 61000-4-2
Electrostatic discharge immunity (Performance criterion B)
IEC 61000-4-3
RF electromagnetic field immunity (Performance
criterion B)
3
IEC 61000-4-4
Electrical fast transient/burst immunity (Performance
criterion B)
IEC 61000-4-5
Power line surge immunity (Performance criterion B)
IEC 61000-4-6
Conducted RF immunity (Performance criterion B)
4
IEC 61000-4-11
Voltage dips and interruptions immunity (Performance
criterion B)
EN 61000-3-2
AC power line harmonic emissions
EN 61000-3-3
Voltage changes, fluctuations and flicker
1
Emissions that exceed the levels required by this standard may occur when this equipment
is connected to a test object.
2
To ensure compliance to the standards listed above, attach only high quality shielded
cables to this instrument. High quality shielded cables typically are braid and foil types that
have low impedance connections to shielded connectors at both ends.
3
The increase in trace noise while subjected to a test field (3 V/m over the frequency range
80 MHz to 1 GHz, with 80% amplitude modulation at 1 kHz) is not to exceed 8 major
divisions peak-to-peak. Ambient conducted fields may induce triggering when the trigger
threshold is offset less than 4 major divisions from ground reference.
4
The increase in trace noise while subjected to a test field (3 V/m over the frequency range
150 kHz to 80 MHz, with 80% amplitude modulation at 1 kHz) is not to exceed
2 major divisions peak-to-peak. Ambient conducted fields may induce triggering when the
trigger threshold is offset less than 1 major division from ground reference.
