Tektronix TDS7054 User Manual

Appendix A: Specifications
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
A-9
Table A- 2: Channel input and vertical specifications (Cont.)
Characteristic Description
DC voltage measurement accuracy, TDS7104 &
TDS7054
Measurement type DC accuracy (in volts)
Sample acquisition mode,
typical
Absolute measurement of any waveform
point, and High, Low, Max, and Min
measurements
±[(1.0% × | reading -- net offset | ) +
offset accuracy + (0.13 div × V/div
setting) + 0.6 mV]
Delta voltage measurement between any
two points acquired under the same
setup and ambient conditions, and all
other automatic measurements
±[(1.0% × | reading | ) + (0.26 div ×
V/div setting) + 1.2 mV]
n Average acquisition mode
(≥16 averages)
Absolute measurement of any waveform
point, and High, Low, Max, and Min
measurements
±[(1.0% × | reading -- net offset | ) +
offset accuracy +( 0.06 × V/div)]
Delta voltage measurement between any
two points acquired under the same
setup and ambient conditions, and all
other automatic measurements
±[(1.0% × | reading | ) + (0.1 div ×
V/div setting) + 0.3 mV]
Net offset is the nominal voltage that must be applied to the channel to bring the
trace to center screen. Net offset = offset -- ( position × volts/division) and is
expressed in volts
n DC voltage measurement accuracy,
TDS6604, & TDS6404
Measurement type DC accuracy (in volts)
Average acquisition mode
(≥16 averages)
10 mV/div to 99.5 mV/ div ±[(2% +(2% × | net offset/1V | )) ×
| reading -- net offset | + offset accuracy
+ 0.08 division × V/division]
≥100 mV/div ±[(2% +(2% × | net offset/ 10V | )) ×
| reading -- net offset | + offset accuracy
+ 0.08 division × V/division]
Delta voltage measurement between any
two averages of ≥16 waveforms
acquired under the same setup and
b
i
d
i
i
10 mV/div to 99.5 mV/ div ±[(2% +(2% × | net off s et/1V | )) ×
| reading | + 0.16 division ×
V/division setting]
q
p
ambient conditi ons
≥100 mV/div ±[(2% +(2% × | net offset/10V | )) ×
| reading | + 0.16 division ×
V/division setting]
Net offset is the nominal voltage that must be applied to the channel to bring the
trace to center screen. Nett offset = offset -- ( position × volts/division) and is
expressed in volts
