Appendix A: Specifications
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
A-11
Table A- 2: Channel input and vertical specifications (Cont.)
Characteristic Description
Analog bandwidth with P7330 active probe,
typical
C
S
A
7
4
0
4
a
n
d
T
D
S
7
4
0
4
DC 50 Ω coupling, Full bandwidth, operating ambient 15 °Cto30°C, derated by 20
MHz/°C above 30 °C
CS
A
7404
a
nd TDS7404
SCALE range Bandwidth
2mV/divto3.9mV/div CSA7404 & TDS7404:
DC to 1 GHz
4mV/divto9.9mV/div CSA7404 & TDS7404:
DC to 1.25 GHz
≥10 mV/div CSA7404 & TDS7404:
DC to 3.5 GHz
n Analog bandwidth
TDS7104 & TDS7054
DC 50 Ω coupling, bandwidth limit set to Full, operating ambient ≤30 °C, derated
by 2.5 MHz/°C above 30 °C
SCALE range Bandwidth
1mV/divto1.99mV/div TDS7054: DC to 450 MHz
TDS7104: DC to 500 MHz
2mV/divto4.98mV/div TDS7054: DC to 500 MHz
TDS7104: DC to 600 MHz
5mV/divto9.95mV/div TDS7054: DC to 500 MHz
TDS7104: DC to 750 MHz
10 mV/div to 1 V/div TDS7054: DC to 500 MHz
TDS7104: DC to 1 GHz
Analog bandwidth limit, typical
TDS7104 & TDS7054
Selectable between 20 MHz, 250 MHz, or Full
Calculated rise time, typical
1
TDS6604 70 ps
CSA7404, TDS7404, & TDS6404 100 ps
TDS7254 160 ps
CSA7154 & TDS7154 240 ps
