Tektronix TDS7054 User Manual

Appendix A: Specifications
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
A-13
Table A- 2: Channel input and vertical specifications (Cont.)
Characteristic Description
Step response settling errors, typical Full bandwidth
CSA7404, CSA7154, TDS7404,
T
D
S
7
2
5
4
&
T
D
S
7
1
5
4
Full bandwidth
TDS7254, & TDS7154
SCALE range and step amplitude Settling error at time after step
2 mV/div to 99.5 mV/ div,
with ≤ 1.5 V step
20 ns: ≤ 2%
1ms:≤ 0.1%
100 mV/div to 1 V/div,
with ≤ 3Vstep
20 ns: ≤ 2%
1ms:≤ 0.2%
TDS7104 & TDS7054 Bandwidth limit set to Full
SCALE range and step amplitude Settling error at time after step
1 mV/div to 100 mV/di v,
with ≤ 2Vstep
20 ns: ≤ 0. 5%
100 ns: ≤ 0. 2%
20 ms: ≤ 0.1%
101 mV/div to 1 V/div,
with ≤ 20 V step
20 ns: ≤ 1. 0%
100 ns: ≤ 0. 5%
20 ms: ≤ 0.2%
1.01 V/div to 10 V/div,
with ≤ 200 V step
20 ns: ≤ 1. 0%
100 ns: ≤ 0. 5%
20 ms: ≤ 0.2%
TDS6604 & TDS6404 Full bandwidth
SCALE range and step amplitude Settling error at time after step
10 mV/div to 99.5 mV/ div,
with ≤ 1.5 V step
20 ns: ≤ 2%
1ms:≤ 0.1%
100 mV/div to 1 V/div, with ≤ 3Vstep 20 ns: ≤ 2%
1ms:≤ 0.2%
