Appendix A: Specifications
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
A-15
Table A- 2: Channel input and vertical specifications (Cont.)
Characteristic Description
n Offset accuracy Net offset is the nominal voltage that must be applied to the channel to bring the trace
to center screen. Net off s et = offset -- ( position × volt s/division). Offset accuracy is
the accuracy of this voltage level.
CSA7404, CSA7154, TDS7404,
SCALE range Offset accuracy
TDS7254, & TDS7154
2mV/divto9.95mV/div ±(0.2% ×| net offset | + 1.5 mV + 0.1
div ×V/div setting)
10 mV/div to 99.5 mV/ div ±(0.35% ×| net offset | + 1.5 mV + 0.1
div ×V/div setting)
100 mV/div to 1 V/div ±(0.35% ×| net off s et | + 15 mV + 0.1
div ×V/div setting)
TDS7104 & TDS7054 SCALE range Offset accuracy
1 mV/div to 100 mV/di v ±(0.2% ×| net offset | + 1.5 mV +
0.1 div ×V/div setting)
101 mV/div to 1 V/div ±(0.25% ×| net off s et | + 15 mV +
0.1 div ×V/div setting)
1.01 V/div to 10 V/div ±(0.25% ×| net offset | + 150 mV +
0.1 div ×V/div setting)
TDS6604 & TDS6404 SCALE range Offset accuracy
10 mV/div to 99.5 mV/ div ±(0.5% ×| net offset | + 1.5 mV +
0.1 div ×V/div setting)
100 mV/div to 1 V/div ±(0.5% ×| net offset | + 15 mV + 0.1 div
×V/div setting)
