Appendix B: Automatic Measurements Supported
B-10
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
Table B- 2: Supported measurements and their definition (Cont.)
Measurements Annotation descri ptions
Time
measurement
annotations
These annotations are not visible when the reference level units are absolute instead of a percentage.
Rise Time 2 horizontal arrows facing each other at the high and low ref indicating the start and end time.
In detailed mode there are 2 horizontal bars indicating the high and low.
Fall Time 2 horizontal arrows facing each other at the high and low ref indicating the start and end time.
In detailed mode there are 2 horizontal bars indicating the high and low.
+Duty Cyc 3 horizontal arrows on the mid ref indicating the start, mid, and end time. End arrows point
toward each other and the mid arrow points toward the positive part of the cycle.
In detailed mode there are 2 horizontal bars indicating the high and low.
--Duty Cyc 3 horizontal arrows on the mid ref indicating the start, mid, and end time. End arrows point
toward each other and the mid arrow points toward the negative part of the cycle.
In detailed mode there are 2 horizontal bars indicating the high and low.
Pos Width 2 horizontal arrows facing each other at the mid ref indicating the start and end time.
In detailed mode there are 2 horizontal bars indicating the high and low.
Neg Width 2 horizontal arrows facing each other at the mid ref indicating the start and end time.
In detailed mode there are 2 horizontal bars indicating the high and low.
Period 2 horizontal arrows facing each other at the mid ref indicating the start and end time.
In detailed mode there are 2 horizontal bars indicating the high and low.
Freq 2 horizontal arrows facing each other at the mid ref indicating the start and end time.
In detailed mode there are 2 horizontal bars indicating the high and low.
Delay 2 horizontal arrows pointing toward each other at their own mid refs indicating the
start and end time. In detailed mode there are 4 horizontal bars indicating the highs and lows.
More
measurement
annotations
Area None
Cyc Area 2 horizontal arrows facing each other at the mid ref indicating the start and end time.
In detailed mode there are 2 horizontal bars indicating the high and low.
Phase 3 horizontal arrows indicating the crossi ng positions and 4 horizontal bars
indicating the highs and lows.
Burst Wid 2 horizontal arrows at the mid ref indicating the start and end time.
In detailed mode there are 2 horizontal bars indicating the high and low.
